ANME CUT NOZZLE 1/32″/0.8MM
Login to see prices
SKU: 701208Nozzle Size = 0.8mm (1/32″) | BAR Acetylene = 0.14 | BAR Oxygen = 1.5 – 2.0
General Purpose hand cutting Acetylene Nozzle. Longer than standard ANM Nozzle to give improved backfire resistance and accessibility. Type 5 18/90. Cutting Nozzle Options:
| Plate Thickness | Nozzle Size (Metric) | Nozzle Size (Imperial) | Bar Acetylene | Bar Oxygen |
| 3mm – 6mm | 0.8mm | 1/32” | 0.14 | 1.5 - 2.0 |
| 5mm – 12mm | 1.2mm | 3/64” | 0.21 | 2.0 – 3.0 |
| 10mm – 75mm | 1.6mm | 1/16” | 0.14 | 3.0 – 4.0 |
| 25mm – 90mm | 2.0mm | 5/64” | 0.14 | 3.5 – 4.5 |
| 90mm – 150mm | 2.4mm | 3/32” | 0.21 | 4.0 – 5.0 |
| 190mm – 300mm | 3.2mm | 1/8” | 0.28 | 6.0 – 7.0 |
Additional Information
| Length | 0.8 cm |
|---|---|
| Plate thickness | 3.0mm 6.0mm |
| Nozzle specifications | Type 5 18/90 |
| Nozzle type | Cutting |
| Anm size | Long |
| Purpose | General pupose |
| Colour | Bronze, rose gold |
| Material | Brass, copper, metal |
| Gas equipment type | Nozzle |
| Set size | Single piece set/item |
