Welding Helmet

Variable Sensitivity and Full Face Coverage

Moulded Construction, the WH-1 is both slim and lightweight in construction. Manufactured from a high impact polyamide nylon material which ensures the helmet provides high levels of comfort and durability. Full Face Coverage and Solar Powered. A curved design with a clear spatter shield over the optics provides maximum clarity. The helmet is fully adjustable to suit all head and body types. Features full neck coverage and locking headgear . The helmet is powered by a solar cell. Internal battery life expectancy is 6 years. Fast Switching The auto on wide view lens switches from light to dark in 1/30,000th of a second and offers continuous eye protection against UV and IR radiation, even in the light state mode. Filters The welding filter has 2 sensors that react independently as the welding arc is struck enabling the almost instantaneous darkening of the filter. The switching sensitivity knob is located on the inside of the helmet and allows the helmet to be tuned to work in different ambient light levels. Shade 4 light state, ideal for welding preparation.

Weight	0.466 kg
Viewing Size	96mm x 39mm (3.78" x 1.54")
Style & Design	Black
External Shade Control	Yes
Shade	Sep-13
Light State	DIN Shade 4
Dark State	DIN Shade 9 to 13 Variable
Switching Time Light to Dark	1/30,000 of a Second (Automatic Adjustment)
Delay	Variable
Sensitivity	Variable
UV/IR Protection	Permanent Shade DIN16
Power Supply	Solar Cells with Built-In Battery Pack
Battery Life Expectancy	6 years
Minimum Amp Requirement	10A
Power On/Off	Fully Automatic
Material	High Impact Polyamide Nylon
Suitable for	Welding Preparation
Warranty	12 Months Guarantee
Conforms To	BS EN 166:2002, BS EN 175, BS EN 175:1997, BS EN 379, CE and BS EN 379:2003+AI:2009, EN 166
