XP CCMS (R45) GAS WELDING WIRE (1.6MM) 5KG
Login to see prices
SKU: XP10600Oxy-Fuel Welding, CCMS Gas Rods/Wire (XP) suitable for joining tubes and plates. Highly fluid weld metal.
- Solid unalloyed copper coated wire designed for oxy-fuel welding applications.
- Suitable for welding mild steel plates, sheets, pipes, and other components where high mechanical strength properties are not critical requirements.
- Produces homogeneous and soft weld deposits with excellent malleability
Additional Information
| Weight | 5 kg |
|---|---|
| Length | 1000 cm |
| Width | 1.6 cm |
| Material | Mild steel |
| Base materials | S185, s235jr, st33, st52, st35, st35.8, 1.0035, 1.0561, 1.0308, 1.0305, astm a36, a106 grades a/b, a139 grade a, a216 grades wca/wcb/wcc, a234 grade wpb |
| Size | 1.6mm |
| Chemical composition (%) | Cr = 0.15, cu = 0.35, s = 0.025, v = 0.03, c = 0.03 min 0.12 max, mn = 0.35 min 0.65 max, mo = 0.30, ni = 0.30, p = 0.03, si = 0.01 min 0.20 max |
| Elongation | 20% (ns) |
| Tensile strength mpa | 400 (≥310) |
| Yield strength mpa | 280 (ns) |
| 0.2% proof stress rp | ≥260mpa |
| Impact iso v | 30j (ns) |
| Standards | Aws a5.2: r45, en iso 20378: o i |
| Set size | Single box |
| Gas equipment type | Gas welding rods |
| Packaging type | Pap 20 tube |
