XR935H Welding and Grinding Helmet

Variable Sensitivity and Full Face Coverage

£0.00 excl. TAX

- +

The XR935H Everyday Light Reactive Welding and Grinding Helmet is both slim and lightweight in construction. Manufactured from a high impact polyamide nylon material which ensures the helmet provides high levels of comfort and durability. Full Face Coverage and Solar Powered. A curved design with a clear spatter shield over the optics provides maximum clarity. The helmet is fully adjustable to suit all head and body types. Features full neck coverage, locking headgear and automatic power on/off switch. The helmet is powered by a solar cell, there is no need for external batteries or cables. Internal battery life expectancy is 6 years.

The auto on wide view lens switches from light to dark in 1/30,000th of a second and offers continuous eye protection against UV and IR radiation, even in the light state mode. The grinding switch is conveniently located on the outside of the helmet. The switch locks the filter in the light state (Shade 4) to enable the helmet to be used as a grinding visor.

The welding filter has 2 sensors that react independently as the welding arc is struck enabling the almost instantaneous darkening of the filter. The switching sensitivity knob is located on the inside of the helmet and allows the helmet to be tuned to work in different ambient light levels. All Parweld filters have a Shade 4 light state, ideal for welding preparation.

Weight 0.466 kg
Viewing Size

100mm x 41mm (3.94” x 1.62”)

Cartridge Size

110mm x 90mm (4.33” x 3.54”)

Style & Design

Black

Grind Mode

Yes

External Shade Control

Yes

Shade

Sep-13

Light State

DIN Shade 4

Dark State

DIN Shade 9 to 13 Variable

Dark to Light

0.1-1.0 Seconds

Switching Time Light to Dark

1/30,000 of a Second (Automatic Adjustment)

Delay

Variable

Sensitivity

Variable

UV/IR Protection

Permanent Shade DIN16

Power Supply

Solar Cells with Built-In Battery Pack

Battery Life Expectancy

6 years

Minimum Amp Requirement

10A

Power On/Off

Fully Automatic

Storage Temperature

-20ºC to +70ºC (-4ºF to -158ºF)

Operating Temperature

-10ºC to +60ºC (14ºF to 140ºF)

Material

High Impact Polyamide Nylon

Suitable for

TIG Welding

Warranty

12 Months Guarantee

Conforms To

BS EN 166:2002, BS EN 175, BS EN 175:1997, BS EN 379, CE and BS EN 379:2003+AI:2009, EN 166
