170A AUTOMOTIVE MIG 240V

SKU: XTE171

Also Includes: 3m Input Cable, 3m Earth Lead, Gas Hose and Integrated Trolley

Compact Automotive 230V Single Phase MIG Transformer Power Source Machine from Parweld. The XTE 171C cabinet can accept a gas cylinder and its large wheels mean it is easily portable and can be moved from job to job, making the welding machine very versatile. The XTE 171C has a DC Output and when combined with the correct type of wire it is suitable for welding mild steel, stainless steel and aluminium. 8 voltage steps allow fine tuning. The feed box ensures reliable feeding of 0.6mm and 0.8mm wires. Key Features Include:

230V Single Phase Machine
Euro Torch Connector
165A @ 15% Duty Cycle
2 Roll Drive (Metal Feed Box)
8 Voltage Steps
Stand for gas cylinder (half bottle)
Polarity can be changed for gasless welding
Built in gas valve
Forced Air Fan Cooling
Overload warning indicator
Infinitely variable wire speed
Holds 5kg wire spools
Supplied with 3m Earth Lead

Additional Information

Weight	38.3 kg
Length	705 cm
Width	420 cm
Height	630 cm
Torch and regulator	Machine only
Phase	Single phase
Machine style	Compact
Machine type	Transformer
Maximum current	165a dc
Duty cycle	165a @ 15% duty cycle
Voltage	19 37v
Voltage steps	8
Input voltage	230v 1p
Input current (eff)	27a
Feed box	2 roll drive, metal box
Output	Dc
Wire feed speed	1.5 14mm/min, infinitely variable
Wire size	0.6 0.8mm
Spool size	200mm (5kg), 300mm (15kg)
Minimum fuse rating	16a
Kva	6.45
Generator size (requires avc)	8 kva
Enclosure protection	Ip21s
Cooling	Air, fan, forced
Comes with	3m earth lead, euro torch connector, stand for gas cylinder
Ideal for welding	Aluminium, mild steel, stainless steel
Special features	Built in gas valve, ease of movement, large wheels, overload warning indicator
Mig machine type	Automotive, transformer
