XTM 160A SINGLE PHASE MIG INVERTER
Login to see prices
SKU: XTM161IAlso Comes With: 3m Input Cable, 3m Earth Lead and Gas Hose
Portable 230V Single Phase MIG Power Source Inverter Welding Machine from Parweld. The XTM 161i is able to cope with inputs which fluctuate by +/-15% & can be used with the majority of generators. The smooth DC output ensures excellent arc characteristics. Materials up to 4mm can be welded with ease. Synergic control provides rapid setting. Lightweight construction means the machine is very portable and the removable Euro connection torch makes for easy transport and storage. Can be used in MMA, Lift TIG, MIG manual and synergic with or without GAS. Wire sizes of 0.8-1.0mm can be used with ease. The machine is housed in a steel case with an integrated carry handle. Key Features Include:
- 230V Single Phase Machine
- Synergic MIG
- Lift TIG and MMA Welding
- Compact and Portable
- 160A @ 40% Duty Cycle
- Gas or Gasless Operation Options
- 2T / 4T Trigger Latching
- Accepts 5kg (200mm) Spools
- Supplied with 3m Earth Lead
Additional Information
| Weight | 15.5 kg |
|---|---|
| Length | 469 cm |
| Width | 223 cm |
| Height | 421 cm |
| Torch and regulator | Machine only |
| Phase | Single phase |
| Machine style | Compact, portable |
| Machine type | Inverter |
| Maximum current | 160a dc |
| Duty cycle | 160a @ 40% duty cycle |
| Input voltage | 230v 1p |
| Voltage | 13.5 22v |
| Feed box | 2 roll drive |
| Input current (eff) | 16.3a |
| Output | Dc |
| Wire feed speed | 2 15m/min |
| Wire size | 0.6 0.8mm |
| Spool size | 200mm (5kg), 100mm (1kg) |
| Minimum fuse rating | 16a |
| Kva | 7.7 |
| Generator size (requires avc) | 10 kva |
| Cooling | Air, fan, forced |
| Comes with | 3m earth cable, 3m input cable, gas hose |
| Ideal for applications | Agricultural, diy, light industrial manufacturing, maintenance repair, automotive |
| Special features | 2t/4t trigger latching, gas or gasless operation, lift tig and mma, synergic mig |
| Mig machine type | Inverter |
| Warranty | 5 year warranty |
| Standards | Ip23s, iso/iec 60974 1, iso/iec 60974 6 & rohs compliant |
